Product Summary

The TLP521-1GB is a programmable controller. It consists of a photo-transistor optically coupled to a gallium arsenide infrared emitting diode.

Parametrics

TLP521-1GB absolute maximum ratings: (1)storage temperature range, Tstg: -65 to 125℃; (2)operating temperature range, Topr: -55 to 100℃; (3)lead soldering temperature, Tsol: 260(10s)℃; (4)total package power dissipation, PT: 250mW; (5)total package power dissipation derating (Ta≥25℃), △PT/℃:-02.5mW/℃; (6)isolation voltage, BVS: 2500(AC, 1min.,R.H.≤60%) Vrms.

Features

TLP521-1GB features: (1)collector-emitter voltage: 555V(min); (2)current transfer ratio: 50%(min); (3)rank GB: 100%(min); (4)isolation voltage: 2500Vrms(min).
